Applications

Laboratory and industrial radiometry Skin and SPF testing Clinical studies

Phototherapy Environmental monitoring

Material testing UVB transmission measurements

Agriculture
Features

High sensitivity Dynamic range 2*105

Excellent long term stability Cosine corrected

NIST traceable calibration Radiometric and Biological units

Specifications

Angular response

5% for angles <60°

Range

PMA 2101 - 200 [MED/Hr]
1,160 [µW/cm2]

PMA 2101S-UVS - 50 [MED/H
300 [µW/cm2]
Calibrated to UV Solar Simulator Spectrum

PMA 2102C - 20 [MED/H]
120 [µW/cm2]
Weatherproof, internal temperature compensation

PMA 2104-UW - 20 [MED/H]
120 [µW/cm2]
Underwater housing, internal temperature compensation

Display resolution

PMA 2101 - 0.001 [mw/cm2], 0.01[W/m2]

PMA 2101S-UVS - 0.001 [mw/cm2], 0.01[W/m2]

PMA 2102C - 0.001 [mw/cm2], 0.01[W/m2]

PMA 2104-UW - 0.001 [mw/cm2], 0.01[W/m2]

Operating environment

32 to 120 °F (0 to +50 °C) no precipitation

Temperature coefficient

1% /°C for solar radiation

Cable

5ft (1.5m)

Diameter

1.6" (40.6 mm)

Height

1.8" (45.8 mm)

Weight

7.1 oz. (200 grams)
Spectral Response

Fig. 3
Literature

• UVB SENSOR PMA 2101 BIOLOGICALLY-WEIGHTED ERYTHEMA Sensors_PMA2101.pd
Solar Light offers sensor and detector options for use in a wide range of applications.
Sensor and Detector Options
Sensors must be used with a Solar Light Radiometer.
Included Accessories

1 year Standard Warranty

SOLAR LIGHT COMPANY warrants that the equipment has been carefully tested, inspected and left the Factory in proper working condition, free of visible defects.  SOLAR LIGHT COMPANY warrants the equipment to be free from defects in material and workmanship, under normal use and operation, for a period of one (1) year after the date of initial operation, or demonstration; or eighteen (18) months from the date of shipment from the Factory; or whichever occurs first. The warranty is limited to the free replacement of all-defective parts and free labor during the first year of warranty.  Defective parts replaced under this warranty shall become the property of SOLAR LIGHT COMPANY. The above stated Warranty is subject to the following conditions: Equipment being installed within the United States of America, Canada, or sold by authorized SOLAR LIGHT COMPANY representatives or their agents outside the continental United States. The equipment being installed is operated and maintained in accordance with SOLAR LIGHT COMPANY’s operating instructions, maintenance instructions and specifications. Utilization of only SOLAR LIGHT COMPANY’s authorized parts and components.  The utilization of a duly authorized representative for all work performed on SOLAR LIGHT COMPANY equipment during the warranty period.  Any variation(s) to the above warranty must be in writing and mutually acceptable by SOLAR LIGHT COMPANY and the customer. The warranty shall not apply to damages resulting from errors in installation, nor shall it apply to any equipment, which has been subject to damages, alterations or misuse by the purchaser.  Parts of the equipment, which would be generally considered as expendable service items during normal use, such as fuses, lamps, detector shields, etc., are not covered under the warranty. THERE ARE NO WARRANTIES, WHICH EXTEND BEYOND THIS DESCRIPTION, AND EXPRESSLY NO IMPLIED WARRANTY OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.  IN NO EVENT SHALL SOLAR LIGHT COMPANY BE LIABLE FOR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OR ANTICIPATED LOSS OF PROFITS SUFFERED BY THE PURCHASER.
